Custom work in machine building
Whether you are looking for a complete machine solution or need custom assemblies — at Assink & Schipholt you are assured of proven craftsmanship and technical expertise.
- 10 t
- max. piece weight
- 8 m
- max. build height
- 3100 mm
- bend length
A dependable partner
- Stainless steel
- Aluminium
- Brass
- Steel
- OEM machine building
- Electronics
- Food industry
- Equipment manufacturing
In practice such a project usually starts from an existing set of drawings or from an assembly currently spread across several suppliers. We then take the lead: sheet metal and welded construction work we produce ourselves, machined parts we have made by a regular partner, and the assembly happens with us again. You keep a single point of contact and one party responsible for the dimensions of the whole.
Machine building imposes requirements that go beyond the individual parts. A frame has to stay flat after welding, holes still have to line up after blasting and coating, and an enclosure has to fit without anything being adjusted on site. That is why we set the welding sequence and the measuring points during production engineering, and check the critical dimensions right after welding rather than only at final inspection.
For OEMs producing on call-off we deliver just in time, so that called-off assemblies do not sit with you as stock. We record the call-off rhythm and the related arrangements per customer.
From drawing to delivery
Complete machines
The full route from design to handover — sheet metal work, construction and assembly.
Individual assemblies
Functional modules such as support structures and frames.
Sheet metal parts
Housings, panels and enclosures in stainless steel, aluminium or brass.
Machined parts
CNC machining of shafts, fasteners and components.
Mechanical assemblies
Assembling parts into working systems.
Specifications
Indicative values — to be confirmed per project- 2D cutting
- Trumpf TruLaser 3040 fibre laser
- Tube and profile
- Trumpf TruLaser Tube 3000
- Press braking
- servo-electric press brake with a working length up to 3100 mm
- Welded assemblies
- up to 10 tonnes piece weight and 8 m build height
- We produce ourselves
- sheet metal and welded construction work
- Via a regular partner
- machined parts
- Assembly
- with us again — one point of contact for the dimensions of the whole
- Standards
- ISO 9001, welding under ISO 3834-2, load-bearing structures under EN 1090-1
- Delivery
- just in time for OEMs producing on call-off
What to send us
Request a quote- The PDF set of drawings and the 3D STEP file
- The required quantities
- The call-off rhythm
- We assess manufacturability, indicate which parts we make ourselves and which come from our partner, and record that before production starts
Frequently asked questions
Do you build complete machines or only individual parts?
Both. We supply complete machines from design to handover, individual assemblies such as support structures and frames, and separate sheet metal and construction parts. Which form suits best depends on how much you want to keep in house.
Do you carry out the machining work yourselves?
No. Turning, milling, drilling and boring are made by a regular partner. We handle the coordination, the incoming inspection and the assembly, so that it remains a single order and a single point of contact for you.
How heavy and how large may an assembly be?
Up to 10 tonnes unit weight and 8 metres in height. Five overhead cranes of 5 tonnes are installed in the hall; by lifting in tandem we move loads of up to 10 tonnes.
Do you deliver just in time on call-off?
Yes, we do so for several OEM customers. The call-off rhythm, the batch size and the accompanying stock arrangements are agreed per customer, so that called-off assemblies do not end up sitting in your stock unnecessarily.
Which certifications do you hold for machine building?
We work under ISO 9001 for the quality management system, ISO 3834-2 for fusion welding and EN 1090-1 for the execution of steel and aluminium structures.
